Features
• Ultra-flat, space-saving design
• Stirring speed range: 15 - 1500 rpm
• Automatic rotation-reversing stirring for better mixing results
• Constructed of chemically resistant materials
• Slip-resistant and stable
Catalogue No. | Voltage [VAC] | Frequency [Hz] | Motor input rating |
Motor output rating |
Stirring speed range | Max. load capacity [kg] |
01-3204 | 100-240 | 50/60 | 5W | 3W | 15-1500rpm |
2.0 |
Dimension of work plate [mm] | Material | Max. stirring quantity [L, H2O] | Dimension [W × D × H, mm] |
Weight [kg] |
Permissible ambient temperature [°C] |
Permissible relative humidity |
90 × 90 | ABS | 0.8 | 175 × 120 × 15 | 0.3 | 5-40 |
80% |
